For sale is a High End Systems Cyberlight SV (studio version). Quieter operating full featured luminaire, see below. This is a moving-mirror light fixture. Unit is fully functional with minimal use in a fixed install over the years but sold as-is with no guarantees. 208V unit, not a 120V. This auction is for (1) unit, we have a total of 4 available as shown in the photo, check the other auctions we have listed for the other units. These units are large and heavy, please bring a vehicle large enough to accommodate transport, and someone to help lift, as we cannot help with loading, they are approx 100lbs.


Cyberlight® Features
The Cyberlight features can be categorized into four main areas, listed separately below: control/
information features, lamp, optics, effects, and other features.
Control/information features
• Remote system enable/disable.
• “Info” LED displays lamp hours, lamp strikes, lamp voltage, lamp current, fixture voltage,
fixture temperature, and the fixture version number for at-a-glance monitoring (no controller is
required).
• Can be controlled by Lightwave Research (LWR) or standard USITT DMX 512 protocol:
• Use LWR protocol for online software uploads and control with High End Systems’ topof-the-line Status Cue system, for uploads only with the Cyberlight Upload Module, and
for control only with the Cyberlight LCD controller.
• Use DMX 512 protocol if the Cyberlight is on the same link as other vendors’ control
equipment.

Lamp
• 1200 watt MSR/MSD lamp; 5600° Kelvin color temperature
• 750-hour rated lamp life
• Quick lamp change and optimization
Optics
• Computer-optimized reflector and lens assembly for maximum output
• Enhanced mirror increases efficiency
• Motorized zoom control (Cyberlight CL and SV models only; the CX has a 3-position zoom
at 12°, 14°, and 18°)
• Zoom angle 12° to 18°—Cyberlight CL and SV only
• Motorized focus control
• Motorized variable frost from hard edge to soft edge
• Smooth, precise micro-stepped beam positioning
• 100% dimming, fade to black
• 170° pan – 110° degrees tilt
• Break-resistant mirror
Effects
• 16 million colors available via sophisticated dichroic subtractive CYM (cyan-yellow-magenta)
color model —Cyberlight CL and SV only
• Eight-position indexed color wheel with a versatile selection of richly-saturated dichroic colors
plus open (white), custom dichroic filters available
• Upward, downward, and centered color correction
• Variable speed (forward and reverse 0-50 RPM) rotating lithos (from 0° to 360°) with
replaceable patterns (4 lithos plus open)
• Eight-position fixed litho wheel with seven easily-replaceable LithoPatterns glass lithos
standard
• Litho mixing effects: rotating over fixed, or fixed over fixed
• Eight-position effects wheel, including multi-image prism effect, split color effect and
subtractive color dichroic mosaic effect
• Infinitely-variable frost effect—Cyberlight CL and SV only
• De-focus lens effect
• Variable speed motorized iris control
• Variable high-speed strobe shutter (1 to 10 FPS)
• Variable speed mirror scan, litho, and color changes
Introduction Intro-3
Other features
• Pan and tilt swap; pan and tilt invert
• Selectable voltage and frequency
• Circuit breaker protection
• Six transport handles
• High-resolution stepper motors
• Durable black powder coat finish
• Yoke indexing with graduated scale reduces pre-focus time
• Adjustable mirror head deviation ± 20 degrees (pan)
• Thermal overload protection
• Power factor correction
• Meets international standards for safety and electromagnetic compatibility
