Seller Type Municipal/Government Fleet
**To Be Sold Pending Seller Confirmation**
Hours 409
Title Brand No Title - Bill of Sale
Title Status No Title
Drive Status Starts/Runs With Jump
**As-Is/Where-Is: No Guarantee On Roadworthiness Or Drive Status**
Fuel Diesel
Transmission Automatic
Color Yellow
VIN/SERIAL CAT3017DCLJ800710

Manufacturer's Specifications:

ENGINE / POWER
Engine model: Yanmar 3TNV76

Net power: ~ 17.7 hp (13.2 kW) @ 2,200 rpm

Gross power: ~ 24.3 hp (17.9 kW)

Displacement: ~ 1,116 cm³ (≈ 40 in³)

Fuel type: Diesel

WEIGHT / OPERATING WEIGHT
Operating weight (typical, standard configuration): ~ 3,810 lb (≈ 1,728 kg)

Alternate weight with canopy: ~ 3,792 lb (≈ 1,720 kg)

With extended undercarriage and heavier config: up to ~ 4,068 lb (≈ 1,845 kg)

HYDRAULICS / HYDRAULIC SYSTEM
Equipment / travel hydraulic operating pressure: ~ 2,900 psi (200 bar)

Swing hydraulic pressure: ~ 1,813 psi (125 bar)

Auxiliary circuit flows (typical):
 • Primary: ~ 30 L/min (8 gal/min at 170 bar)
 • Secondary: ~ 17 L/min (4.5 gal/min at 200 bar)

Maximum bucket digging force: ~ 4,226 lb (~ 18.8 kN)

Maximum stick (arm) digging force (standard stick): ~ 2,518 lb (~ 11.2 kN)

PERFORMANCE / DIGGING / MOVEMENT
Maximum digging depth: ~ 7.87 ft (≈ 2,400 mm)

Maximum dump (bucket) height: ~ 8.20 ft (≈ 2,500 mm)

Maximum reach at ground level: ~ 12.6 ft (≈ 3,842 mm)

Tail swing radius: ~ 3.84 ft (≈ 1,170 mm)

Travel speed: ~ 1.74 mph – 3.48 mph (≈ 2.8 – 5.6 km/h)

Gradeability: up to 30° (≈ 58% grade)

DIMENSIONS / UNDERCARRIAGE / BLADE
Undercarriage width (retracted): ~ 990 mm (≈ 3 ft 3 in)

Undercarriage width (extended): ~ 1,300 mm (≈ 4 ft 3 in)

Dozer blade width: ~ 990 mm (can extend with undercarriage)

Dozer blade lift / dig depth (when used as dozer): small dozer blade — modest lift / dig depth (blade dig depth ~ minimum)

SERVICE / FLUID CAPACITIES
Fuel tank capacity: ~ 6.3 gal (≈ 24 L)

Hydraulic fluid tank / hydraulic system capacity: modest — appropriate for mini-excavator class

**Disclaimer: The manufacturer's specifications provided are for reference only, and we disclaim any liability for inaccuracies or discrepancies. Specifications may vary by model or trim, and stock photos are used for illustrative purposes only and may not accurately represent the actual product. Please refer to the actual product for precise details.**
