Seller Type Municipal/Government Fleet
**To Be Sold Pending Seller Confirmation**
Hours 268
Title Brand No Title - Bill of Sale
Title Status No Title
Drive Status Starts/Runs
**As-Is/Where-Is: No Guarantee On Roadworthiness Or Drive Status**
Fuel Diesel
Transmission Automatic
Color Yellow
VIN/SERIAL N5C389341

Manufacturer's Specifications:

ENGINE / POWER
Engine: Case Family III 445T/M2, turbocharged 4-cylinder diesel

Displacement: 4.5 L (≈ 272 cu in)

Gross Power: ~ 85 hp (≈ 63 kW)

Net Power: ~ 80 hp (≈ 60 kW) @ 2200 rpm

Max torque: ~ 246 lb-ft (≈ 334 Nm) @ ~1400 rpm

Fuel tank capacity: ~ 31.4 gallons (≈ 119 L)

TRANSMISSION / DRIVE / CHASSIS
Transmission: 4-speed synchromesh with hydraulically-actuated clutches — 4 forward / 4 reverse gears

Max forward speed: ~ 24.5 mph (≈ 39.5 km/h)

Max reverse speed: ~ 29.7 mph (≈ 47.8 km/h)

Drive: Typically 2WD (though other configurations may exist)

WEIGHT & FLUID CAPACITIES
Operating weight (2WD base): ~ 13,359 lb (≈ 6,060 kg)

Maximum working/loaded weight: ~ 16,510 lb (≈ 7,489 kg) depending on configuration/attachments

Hydraulic system fluid capacity: ~ 28 gallons (≈ 106 L)

Engine oil capacity: ~ 3.6 gallons (≈ 13.6 L)

Cooling system fluid capacity: ~ 4.5 gallons (≈ 16.8 L)

Transmission fluid capacity: ~ 5.5 gallons (≈ 20.8 L)

Fuel capacity: ~ 31.4 gallons (≈ 119 L)

LOADER (FRONT) — Bucket / Loader Specs
Bucket capacity: ~ 0.87 cubic yards (≈ 0.67 m³)

Bucket width: ~ 82 in (≈ 2.08 m)

Lift capacity at full height: ~ 6,182 lb (≈ 2,804 kg)

Breakout force (bucket): ~ 9,164 lb (≈ 4,160 kg)

Dump-height clearance (bucket hinge pin): ~ 8.7–8.8 ft (≈ 2,640–2,680 mm)

Dump reach at full height: ~ 2.35 ft (≈ 717 mm)

BACKHOE (REAR) — Digging / Reach / Loading Specs
Configuration Spec
Maximum digging depth — standard stick ~ 14.25 ft (≈ 4,340 mm)
Digging depth — extended stick / “extend-a-hoe” ~ 18.25 ft (≈ 5,560 mm)
Reach from swing-pivot — standard ~ 17.83 ft (≈ 5,440 mm)
Reach from swing-pivot — extended ~ 21.83 ft (≈ 6,650 mm)
Load height (bucket hinge pin) — standard ~ 11.17 ft (≈ 3,400 mm)
Load height — extended stick ~ 13.25 ft (≈ 4,040 mm)
Bucket digging force (standard & extended) ~ 11,212 lb (≈ 5,086 kg)
