The Hayssen Ultima Model 12-19HR is an automated vertical form-fill-seal (VFFS) packaging machine. Its primary function is to efficiently form, fill, and seal bags from a continuous roll of plastic film, making it ideal for a wide range of products.
What This Machine Does:

Forms: It creates a bag from a flat roll of film, shaping it into a tube.

Fills: The product is dispensed into the newly formed bag via an integrated dosing system, such as a pump for liquids or an auger for powders.

Seals: The top of the filled bag is sealed with heat, and the bottom of the next bag is simultaneously created.

Cuts: The finished, sealed bag is cut away, ready for final packaging and distribution.

Key Specifications & Capabilities:

Bag Size Range:

Maximum Bag Width: 8 inches (Slant Seal style)

Minimum Bag Length: 3 inches

*Note: The machine uses film with a tube width of 9-3/16", which determines the finished bag's perimeter.*

Filling & Production Capacity:

Filling System: Comes equipped with a pump (230V) for liquid or semi-liquid products.

Production Speed:

This machine typically operates at a speed of 30 to 60 cycles per minute (CPM).

This translates to an estimated production rate of 1,800 to 3,600 bags per hour.

Note: The actual output depends heavily on the bag size and the product's flow characteristics. Smaller bags can reach the higher end of this range, while larger bags or slow-filling products will result in a lower output.

Film Roll: Supports large film rolls up to 18 inches in diameter with a 3-inch core, minimizing downtime for roll changes.

Technical Requirements:

Electrical: 115V, 1 Phase, 60Hz (Machine) / 230V, 1 Phase, 60Hz (Pump).


--Dimensions L111.00 X W49.00 X H109.00 Inches

--The machine is timed volume controller.

-- Disassembled and ready to Load

--We can help with loading. No cost.

--We can ship You pay for your shipping.
